The QUA Q-SEP® 8012 is an advanced outside-in hollow fiber ultrafiltration (UF) module designed for high-performance water treatment applications. Manufactured using QUA’s proprietary modified thermally induced phase separation (TIPS) method, it features hydrophilic polyvinylidene fluoride (PVDF) membranes known for their high mechanical strength, chemical resistance, and chlorine tolerance. With a membrane area of 80 m² and the ability to handle feed water turbidity up to 100 NTU, the Q-SEP® 8012 ensures superior filtration performance. It operates efficiently under low transmembrane pressures, requiring no separate backwash pump or tank, thereby reducing equipment costs and operational complexity. This module is ideal for applications such as reverse osmosis pretreatment, potable water purification, industrial water filtration, and wastewater recycling.
The QUA Q-SEP® 8012 is an advanced outside-in hollow fiber ultrafiltration (UF) module designed for efficient water treatment in various applications, including municipal and industrial settings.
Manufactured using QUA’s proprietary modified thermally induced phase separation (TIPS) method, the Q-SEP 8012 module features polyvinylidene fluoride (PVDF) membranes. This construction imparts high mechanical strength, chemical resistance, and the ability to handle high feed turbidity levels, making it suitable for challenging water sources.
With a membrane area of 80 m² (861 ft²), the Q-SEP 8012 module offers a filtrate flux range of 40 to 120 liters per square meter per hour (lmh) and operates effectively under transmembrane pressures between 0.3 to 2.0 bar (5 to 30 psi). Its design allows for consistent product water quality, with turbidity levels consistently below 0.1 NTU, even when treating feed water with turbidity up to 100 NTU.
The Q-SEP 8012 module's robust performance and design make it an ideal choice for applications such as pretreatment to reverse osmosis systems, purification of surface and well water for potable applications, filtration of industrial water, and wastewater recycling and reuse.
In summary, the QUA Q-SEP® 8012 ultrafiltration module combines advanced membrane technology with a high surface area design to deliver reliable and efficient water treatment solutions across various industries.
